Lock opening method
Swiping card opening;
485 instruction opening;
Emergency key opening.

Technical Specifications

Work voltage	DC11~13V
Work current	≤ 0.5A
Communication interface	RS485
Work frequency	13.56MHz
Swiping card distance	0 ~ 5 mm
Wire material	UL2464/26AWG/L2000
Work temperature	-20 ~ 60°C
IP rating	IP65 (front)
Material	Zinc alloy: housing, handle
	304 Stainless steel: cam
	PA6 + 30%GF support

Instruction of Usage
1.Wake button: wake up the background controller
2.Remote control opening: the indicator light shines and motor acts. User pulls the handle to open the lock.
3.Key opening: Use a pentagonal key to open the dustproof cap. Insert the electronic key, rotate the lock cylinder clockwise and pull the handle to open the lock. Return the key 45° to ensure automatic locking after closing the handle.
