Lock opening method
Power-on opening; Emergency opening
| Work voltage | DC5V |
| Work current | ≤ 0.3A |
| Power-on time | 15S |
| Communication interface | DO/DI |
| Wire material | UL2464/26AWG/L2000 |
| Work temperature | -40 ~ 60°C |
| IP rating | IP65 (front) |
| Material | Zinc alloy: housing, handle |
| 304 Stainless steel: cam | |
| Q235: support |
Instruction of Usage
1.Opening the handle, gray and orange wires are connected;
Closing the handle, gray and orange wires are disconnected.
2.The stop height can be changed by adjusting the number of washers.
3.Electronic cylinder or mechanical cylinder is optional.
